The Wrangler SystemTM

PERFECT FOR SMALL PRODUCERS, FFA AND 4-H PROGRAMS!

-Excellent for rugged environments and weighing on unlevel surfaces

-Advanced signal filtering provides stable reading on active animals

-14-segment LCD display provides exceptional visibility in all types of weather

-Most economical system

The Wrangler SystemTM Package Includes:
-StockWeighTM 500 Indicator
-StockWeighTM Indicator Mount
-StockWeighTM 3300-24"
-Power Supply AC/DC
The Wrangler EliteTM Package Includes:
-StockWeighTM 500 Indicator
-StockWeighTM Indicator Mount
-StockWeighTM 3300-24"
-Power Supply AC/DC
-Aluminum Platform


SPECIFICATIONS - STOCKWEIGHTM 3300

Gross Capacity 3,300 lb. (1,500 kg.)
Accuracy /1% and /1 display increment
Load Cell Overall Dimensions 3-3/4 Hx8-1/4"Wx16,24&33-1/2" L
Load Cell Cable Length 14'
Resolution
Increment 1 lb. or kg. Range 0-300 lb. or kg.
Increment 2 lb. or kg. Range 300-600 lb. or kg.
Increment 5 lb. or kg. Range 600 lb. or kg.
Power Requirements 12-14 VDC at approx. 1 amp
AC to DC Converter 110 VAC to 13.8VDC @ 1.2 amps

SUGGESTED DECK WIDTH STOCKWEIGHTM 3300
LOAD CELL LENGTH
DECK WIDTH
Minimum
16"
24"
33-1/2"
Maximum
24"
35"
43"
16"
24"
33-1/2"
Deck length is a function of deck substructure.
Manuals provide recommended materials for deck design.

The Digi-StarTM 3300/6600 load cell technology is covered by the following assigned patents - USA - 5.183.126 & 4.744.429: Canada - 1.337.607 & 1.257.782.
